Issue: Vol. 5415 No. 3: 22 Feb. 2024
Type: Article
Published: 2024-02-22
DOI: 10.11646/zootaxa.5415.3.9
Page range: 493-498
Abstract views: 107
PDF downloaded: 36

Stolleagrion foghnielseni (Odonata, Cephalozygoptera, Dysagrionidae) gen. et sp. nov.: a new odonatan from the PETM recovery phase of the earliest Ypresian Fur Formation, Denmark

Department of Research and Collections; Natural History Museum Aarhus; Wilhelm Meyers Allé 10; Aarhus; DK-8000 Aarhus C; Denmark
Beaty Biodiversity Museum; University of British Columbia; Vancouver; British Columbia; Canada; Museum of Comparative Zoology; 26 Oxford Street; Cambridge; Massachusetts; 02138; United States of America
Museum Mors; Skarrehagevej 8; DK-7950 Nykøbing Mors; Denmark; Natural History Museum of Denmark; Øster Voldgade 5-7; DK-1350 Copenhagen K; Denmark
Fur Museum; Nederby 28; DK-7884 Fur; Denmark
Department of Research and Collections; Natural History Museum Aarhus; Wilhelm Meyers Allé 10; Aarhus; DK-8000 Aarhus C; Denmark
Division of Invertebrate Zoology; American Museum of Natural History; NY; NY; 10024USA
Odonata Cephalozygoptera Dysagrionidae Fur Formation PETM recovery phase Ax0

Abstract

We describe the new genus and species Stolleagrion foghnielseni n. gen. et sp. from the Fur Formation in northwestern Denmark based on a single fossil wing. This is the first odonatan described from the earliest part of the PETM recovery phase of the early Eocene. A combination of nine wing character states are considered to be diagnostic of the Dysagrionidae Cockrell only together with the cephalozygopteran head; however, the combination of these nine plus the presence of Ax0 is also diagnostic without the head. By this, we assign Stolleagrion foghnielseni to the Dysagrionidae and reassess the position of other odonates previously treated as cf. Dysagrionidae.



References

  1. Archibald, S.B. & Cannings, R.A. (2021) The head of Cephalozygoptera (Odonata). Zootaxa, 5047 (1), 97–100. https://doi.org/10.11646/zootaxa.5047.1.10 DOI: https://doi.org/10.11646/zootaxa.5047.1.10
  2. Archibald, S.B., Cannings, R.A., Erickson, R.J., Bybee, S.M. & Mathewes, R.W. (2021) The Cephalozygoptera, a new, extinct suborder of Odonata with new taxa from the early Eocene Okanagan Highlands, western North America. Zootaxa, 4934 (1), 1–133. https://doi.org/10.11646/zootaxa.4934.1.1 DOI: https://doi.org/10.11646/zootaxa.4934.1.1
  3. Archibald, S.B., Ware, J.L., Rasmussen, J.A., Sylvestersen, R.L., Olsen, K. & Simonsen, T.J. (2023) The damselfly genus Furagrion Petrulevičius et al. (Odonata, Zygoptera) from the early Eocene Fur Formation of Denmark and the dysagrionid grade. Zootaxa, 5278 (2), 289–317. https://doi.org/10.11646/zootaxa.5278.2.4 DOI: https://doi.org/10.11646/zootaxa.5278.2.4
  4. Bøggild, O.B. (1918) Den vulkanske aske i Moleret samt en oversigt over Danmarks ældre Tertiærbjergarter. Danmarks Geologiske Undersøgelser, II, Række, 33 (1), 1–159. https://doi.org/10.34194/raekke2.v33.6818 DOI: https://doi.org/10.34194/raekke2.v33.6818
  5. Garrison, R.W., von Ellenrieder, N. & Louton, J.A. (2010) Damselfly genera of the New World: an illustrated and annotated key to the Zygoptera. Johns Hopkins University Press, Baltimore, Maryland, 490 pp.
  6. Heilmann-Clausen, C. (1994) Review of Paleocene dinoflagellates from the North Sea region. GFF, 116, 51–53. https://doi.org/10.1080/11035899409546149 DOI: https://doi.org/10.1080/11035899409546149
  7. Heilmann-Clausen, C. (1995) Palæogene aflejringer over Danskekalken. In: Nielsen, O.B. (Ed.), Danmarks geologi fra Kridt til i dag. Aarhus Geokompendier 1. Geologisk Institut, Aarhus Universitet, Aarhus, pp. 69–114. [in Danish]
  8. Heilmann-Clausen, C., Nielsen, O.B. & Gersner, P. (1985) Lithostratigraphy and depositional environments in the Upper Paleocene and Eocene of Denmark. Bulletin of the Geological Society of Denmark, 33, 287–323. https://doi.org/10.37570/bgsd-1984-33-26 DOI: https://doi.org/10.37570/bgsd-1984-33-26
  9. Henriksen, K. (1922) Eocene insects from Denmark. Danmarks Geologiske Undersøgelser, II, Række 37, 1–36. https://doi.org/10.34194/raekke2.v37.6823 DOI: https://doi.org/10.34194/raekke2.v37.6823
  10. Jones, M.T., Percival, L.M.E., Stokke, E.W., Frieling, J., Mather, T.A., Riber, L., Schubert, B.A., Schultz, B., Tegner, C., Planke, S. & Svensen, H.H. (2019) Mercury anomalies across the Palaeocene-Eocene Thermal Maximum. Climate of the Past, 15, 217–236. https://doi.org/10.5194/cp-15-217-2019 DOI: https://doi.org/10.5194/cp-15-217-2019
  11. Jones, M.T., Stokke, E.W., Rooney, A.D., Frieling, J., Pogge von Strandmann, P.A.E., Wilson, D.J., Svensen, H.H., Planke, S., Adatte, T., Thibault, N., Vickers, M.L., Mather, T.A., Tegner, C., Zuchuat, V. & Schultz, B.P. (2023) Tracing North Atlantic volcanism and seaway connectivity across the Paleocene–Eocene Thermal Maximum (PETM). Climate of the Past, 19, 1623–1652. https://doi.org/10.5194/cp-19-1623-2023 DOI: https://doi.org/10.5194/cp-19-1623-2023
  12. Larsen, L.M, Fitton, J.G. & Pedersen, A.K. (2003) Paleogene volcanic ash layers in the Danish Basin: composition and source areas in the North Atlantic Igneous Province. Lithos, 71, 47–80. https://doi.org/10.1016/j.lithos.2003.07.001 DOI: https://doi.org/10.1016/j.lithos.2003.07.001
  13. Madsen, H. & Rasmussen, J.A. (2021) Geologien fortæller: Moler og Fossiler / What geology tells: The mo-clay and its fossils. Museum Mors, 103 pp. ISBN 87-87566-91-5.
  14. Nel, A. & Zheng, D. (2021) The recently proposed odonatan ‘suborder’ Cephalozygoptera: fact or fiction. Palaeoentomology, 4 (2), 165–170. https://doi.org/10.11646/palaeoentomology.4.2.5 DOI: https://doi.org/10.11646/palaeoentomology.4.2.5
  15. Nel, A. & Jouault, C. (2022) The odonatan insects from the Paleocene of Menat, central France. Acta Palaeontologica Polonica, 67, 631–648. https://doi.org/10.4202/app.00960.2021 DOI: https://doi.org/10.4202/app.00960.2021
  16. Pedersen, G.K. & Surlyk, F. (1983) The Fur Formation, a late Paleocene ash-bearing diatomite from northern Denmark. Bulletin of the Geological Society of Denmark, 32, 43–65. https://doi.org/10.37570/bgsd-1983-32-03 DOI: https://doi.org/10.37570/bgsd-1983-32-03
  17. Pedersen, G.K., Pedersen, S.A.S., Bonde, N., Heilmann-Clausen, C., Larsen, L.M., Lindow, B., Madsen, H., Pedersen, A.K., Rust, J., Schultz, P.B., Storey, M. & Willumsen, P.S. (2012) Molerområdets geologi—sedimenter, fossiler, askelag og glacialtektonik. Geologisk Tidsskrift, 2011, 41–135. [in Danish]
  18. Petrulevičius, J.F., Wappler, T., Wedmann, S., Rust, J. & Nel, A. (2008) New Megapodagrionid Damselflies (Odonata: Zygoptera) from the Paleogene of Europe. Journal of Paleontology, 82, 1173–1181. https://doi.org/10.1666/07-091.1 DOI: https://doi.org/10.1666/07-091.1
  19. Riek, E.F. & Kukalová-Peck, J. (1984) A new interpretation of dragonfly wing venation based upon Early Upper Carboniferous fossils from Argentina (Insecta: Odonatoidea) and basic character states in pterygote wings. Canadian Journal of Zoology, 62, 1150–1166. https://doi.org/10.1139/z84-166 DOI: https://doi.org/10.1139/z84-166
  20. Rust, J. (1999) Biologie der Insekten aus dem ältesten Tertiär Nordeuropas. Habilitationsschrift zur Erlangung der venia legendi für das Fach Zoologie. Postdoctoral thesis, Biologische Fakultät der Georg-August-Universität Göttingen, Göttingen, Lower Saxony, 482 pp.
  21. Rust, J, Petrulevičius, J.F. & Nel, A. (2008) The first damselflies from the lowermost Eocene of Denmark, with a description of a new subfamily (Odonata, Zygoptera, Dysagrionidae). Palaeontology, 51, 709–713. https://doi.org/10.1111/j.1475-4983.2008.00780.x DOI: https://doi.org/10.1111/j.1475-4983.2008.00780.x
  22. Röhl, U., Westerhold, T., Bralower, T. & Zachos, J. (2007) On the duration of the Paleocene-Eocene Thermal Maximum (PETM). Geochemistry Geophysics Geosystems, 8 (Q12002), 1–13. https://doi.org/10.1029/2007GC001784 DOI: https://doi.org/10.1029/2007GC001784
  23. Simonsen, T.J., Archibald, S.B., Rasmussen, J.A., Sylvestersen, R.L., Olsen, K. & Ware, J.L. (2022) Danowhetaksa gen. nov. with two species from the early Eocene Ølst Formation from Denmark, the first Palearctic Whetwhetaksidae (Odonata: Cephalozygoptera). Zootaxa, 5099 (5), 586–592. https://doi.org/10.11646/zootaxa.5099.5.5 DOI: https://doi.org/10.11646/zootaxa.5099.5.5
  24. Stokke, E.W., Jones, M.T., Tierney, J.E., Svensen, H.H. & Whiteside, J.H. (2020) Temperature changes across the Paleocene-Eocene Thermal Maximum—anew high-resolution TEX86temperature record from the Eastern North Sea Basin. Earth and Planetary Science Letters, 544, 1–10. https://doi.org/10.1016/j.epsl.2020.116388 DOI: https://doi.org/10.1016/j.epsl.2020.116388
  25. Zachos, J., Pagani, M., Sloan, L., Thomas, E. & Billups, K. (2001) Trends, Rhythms, and Aberrations in Global Climate 65 Ma to Present. Science, 292, 686–693. https://doi.org/10.1126/science.1059412 DOI: https://doi.org/10.1126/science.1059412
  26. Zessin, W. (2011) Neue Insekten aus dem Moler (Paläozän/Eozän) von Dänemark Teil 1 (Odonata: Epallagidae, Megapodagrioniidae), Virgo, Mitteilungsblatt des Entomologischen Vereins Mecklenburg, 14, 64–73.
